How To Assemble Your Pengcheng PCES-1250 Electric Height Adjustable Desk

Pengcheng Home Office ergonomic office electric height adjustable desk Step-by-Step Assembly Process:

The Pengcheng PCES-1250 Height Adjustable Standing Desk Frame is quick and simple to assemble. Here are the steps and some helpful tips to putting together your new sit-stand desk.

*Build and design the desk you want at https://www.pcwy-furniture.com

Click the photo to watch video on Youtube：

 Firstly, take the parts out of the box

Includes: column x 2; table legs x 2; short beams x 2; long beam x 1; crossbeams x 2; controller x 1; wires

Fix the column and table legs with M4 x 12mm screwsPlease do not fully tighten screws until all screws are in placeInstalling non-slip feet

Similarly, install another table legs

Table legs installation completed

Fix the short beams and table legs with M6 x 10mm screws

Please do not fully tighten screws until all screws are in place

Similarly, install another short beam

Short beams installation completed

Fix long beam and table legs with M6 x 10mm screws

Two people working together

Fix one end of the table legs and long beams first with screws

First put all the screws on both sides and stretch to the appropriate length

Please do not fully tighten screws until all screws are in place

Similarly, install the other end of the long beams

Long beam installation completed

Fix crossbeams and table legs with M6 x 10mm screws

Please do not fully tighten screws until all screws are in place

Similarly, install another crossbeam

Crossbeams installation completedFix the controller with M4 x 12mm screws

Connecting circuit

Tied up the neat wires with a cable tie

Height tutorial zeroPress and hold the down button until AES appears

The installation is complete
